AMS SHOT
Cast steel shot for aerospace peening and peen forming
AMS Shot is a cast steel media for peening or peen forming operations, designed to meet the strict requirements of aerospace and military industries (AMS standards, as well as many other proprietary specifications).
Users benefits
Users benefits
SAE AMS 2431 Certified
High Sphericity
High Durability
Performances
Performances
Quality
Strict compliance with many aerospace standards: AMS 2431/1 & 2 (SAE), DMR 71-110 (Safran group), P11TF3-S19 & P11TF8-S11 (General Electric), CSS 119 & CSS 120 (Rolls-Royce), ABP 1-2028 (Airbus), BAC 5730 (Boeing). Other proprietary specifications on demand.
Availability
Manufactured in 3 different aerospace certified plants (Slovenia, France, Japan), for high availability on all sizes and hardness.
Health and Safety
Available under 25 kg and 12,5 kg unit package (on 1000 kg and 500 kg pallets) to prevent musculoskeletal disorders.
Markets and applications
Markets and applications
Aircraft engines components
Aircraft structural parts
Aircraft wings
Specifications
Specifications
| Product Type | SAE AMS 2431/1
ASR (regular hardness) |
SAE AMS 2431/2
ASH (high hardness) |
| Hardness | 45-52 HRc | 55-62 HRc |
| Shot Size | Available from Screen 80 (0.0070) to Screen 10 (0.0787)
ASR/ASH 070, 110, 130, 170, 190, 230, 280, 330, 390, 460, 550, 660, 780 |
|
| Chemical Composition | Carbon: 0.80 min to 1.20 max
Silicon : 0.40 min to 1.50 max Manganese : 1.20 max Phosphorus : 0.05 max Sulfur : 0.05 max |
|
| Density | >7.0 g/cm3 | |
| Standards | AMS 2431/1 : Cast Steel Shot, ASR, Regular Hardness (45 to 52 HRC)
AMS 2431/2 : Cast Steel Shot, ASH, High Hardness (55 to 62 HRC) DMR 71-110 (Safran group) P11TF3-S19 & P11TF8-S11 (General Electric) CSS 119 & CSS 120 (Rolls-Royce) ABP 1-2028 (Airbus) BAC 5730 (Boeing) Other proprietary specifications |
|
| Packaging | METALLIC CANS
12.5/25Kg conical can (or cardboard boxes) on 500 or 1,000Kg pallets BAGS 20Kg bags on 500 Kg or 1,000 Kg pallets |
|
References
References
Amis our clients, we find among others these well-known manufacturers
